Heavy-duty Submersible Desilting Slurry Agitator Pump

Hydroman^® Heavy-duty Submersible Desilting Slurry Agitator Pumps are designed to operate while fully submerged in the slurry, making them critical for efficiently handling highly abrasive and/or corrosive fluids in demanding mining, dredging, quarrying, construction, and wastewater treatment.

Hydroman^®  Agitator Submersible slurry pumpsfeatures a specially designed agitator (often an open-type vortex impeller or propeller) that creates a powerful vortex used to pump a medium with a high dry-matter Content and are excellent for handling abrasive fluids like sludge and mud in industries. Sand, Silt and Slurry Submersible Pumps can transport 70% solids with minimal water such as mining, dredging, wastewater treatment, and construction.

Hydroman^®  Heavy Duty Submersible Solids Handling Agitators Pumps robust construction enables continuous operation in abrasive, corrosive, and deep-submersion environments (up to 50 meters or more), addressing the limitations of surface-mounted slurry pumps in accessing hard-to-reach sediment layers.

Hydroman^® Heavy-duty Submersible Desilting Slurry Agitator Pumps Key Components

▪ Submersible Motor: A waterproof, explosion-proof motor (typically IP68-rated) powers the Submersible Agitator Sand Pump.

▪ Agitation System: Electric Submersible Slurry Pump equipped with high-torque agitators breaks up compacted sediment and suspends solid particles (up to 120mm in diameter) in the liquid, preventing clogging and ensuring uniform slurry consistency.

▪ Pump Body & Impeller: The Submersible mining silica sand pump with agitator body is crafted from wear-resistant materials such as high-chromium alloy to withstand abrasion from hard particles.

▪ Sealing Mechanism: Submersible Electric Drainage slurry agitator pump sealed by double-mechanical seal with oil lubrication prevents slurry infiltration into the motor, extending service life.

▪ Continuous Operation: Submersible Mud Agitator Pumps integrated design ensures synchronous agitation and pumping, avoiding sediment re-deposition and maintaining stable flow rates.

Hydroman^® Heavy-duty Submersible Desilting Slurry Agitator Pump Typical Applications

▪ Mining Industry

Transfer of mineral slurry (e.g., coal, iron ore) from underground sumps to processing plants.

Desilting of tailings ponds to prevent dam blockages and recover valuable minerals.

Agitation of ore pulp to maintain uniform concentration during flotation processes.

▪ Water Conservancy & Environmental Engineering

Dredging of rivers, lakes, and reservoirs to remove sediment and restore water storage capacity.

Desilting of wastewater treatment tanks (e.g., anaerobic digesters) to prevent sludge accumulation.

Cleanup of industrial wastewater containing solid contaminants (e.g., construction debris, chemical sludge).

▪ Construction & Municipal Works

Management of slurry from bored pile construction (e.g., transferring concrete slurry or removing soil sediment).

Desilting of urban drainage systems and stormwater tanks to prevent flooding.

▪ Oil & Gas Sector

Handling of drilling mud (containing rock cuttings) in offshore and onshore drilling operations.

Desilting of oil storage tanks to remove sludge and improve storage efficiency.
