Max. particles: 45mm
Max. concentration: 70%
Max. working depth: ≤ 150m
Agitator or Cutterheads: Available
Sealing arrangement: Double mechanical seal
Materials: Hyperchrome alloy, Cast iron, SS304, SS316L, Duplex SS etc
Hydroman™ 150TJQ Submersible Slurry Pump is a submersible three-phase high power and high volume heavy-duty slurry pump driven by a electric motor. In combination with abrasion-resistant wear parts, the very low speed motor ensures extremely long wear life. The side discharge, spiral design allows smoother passage of the sucked solid matters. The Hydroman pump can be equipped with high pressure jet rings, it can provide extra cutting and suspending capability, notably for the applications where you have compact materials to pump. Hydroman manufactures custom made jet rings and install them on the submersible slurry pump, ready for connection to high pressure slurry pump. Hydroman can also provide the high pressure submersible slurry pump in a complete installation.
▪ Pump complete with standard agitator to put solids in suspension ready for pumping
▪ High abrasion resistance
▪ Low rotation speed
▪ Able to handle up to 70% per weight material density
▪ Cooling jacket
▪ Cutter for seaweed
▪ Temperature and moisture sensor
▪ High Pressure Jet System
▪ Remote controlled flaoting system
▪ Electric pumps are available in 50Hz and 60Hz versions. Pumps are CE certified. Pump with UL/CSA motor available.
Electric submersible slurry pumps. Submersible Dredge pumps, submersible sand pumps, submersible sludge pumps, Submersible dewatering pumps, Submersible gravel pumps and submersible mining pumps!
Hydroman™ TJQ Submersible Slurry Pumps Applications:
|Power Plants||Coal pile run-off||Coal tunnel wash down sumps||Bottom ash sumps||Fly ash||precipitator sumps||Ash pond float sumps|
|Plant waste clean-up sumps||Sand & Clay Mining||Kaolin clay||Sand transport||Clarifier sludge||Red mud decanting||Mineral Extraction & Processing|
|Ball and Sag Mill run off||Cyclone Feed||Magnetite Recovery||Concentrate Sump||Acid Mine Draining||Red Mud Decanting||Thickener Drain Sump|
|Thickener Underflow Sump||Classifier Sludge||Slurry Transport||Tailings Sumps||Mill Rougher Sump||Sand & Gravel||Stone & Pebble|
